| Sensor Attribute | Attribute Value |
| Product Category | Board Mount Pressure Sensors |
| Product Series | GZP191 |
| Pressure Type | Gauge Pressure (Postive and Negative Pressure) |
| Pressure Range | 10/50/100/200kPa |
| Output Type | Analog mV output(Calibrated&Compensated) |
| Offset Output Value | ±1mV |
| FS Output Value | 40±1.5mV |
| Supply Voltage | 10Vdc(Typical Value) |
| Compensated Temperature | 0 to 60°C |
| Operating Temperature | -20 to 85°C |
| Mounting Style | THT(DIP Type) or Manual Soldering |
| Measured Media | Non-corrosive gases |
| Package/SPQ | Tray/45pcs |
